Solar Cell Tester Solar Cell Sun Simulator - Solar Panel Making Machine

Type:

Specification:

Profile:
Solar cell tester is used to test the electrical performance of Mono-Si or Poly-Si solar cell pieces and record the results in files.
Inquiry NOW!

Solar Cell Tester Solar Cell Sun Simulator - Solar Panel Making Machine

Machine Function

Use to test the electrical performance of Mono-Si or Poly-Si solar cell pieces and record the results in files.

Machine Features

1. Key components use import abroad brand

2. A grade spectrum

3. A grade unevenness degree of irradiance

4. four-line measurent,14-bit 4-channel high speed synchronous acquisition card

5. 10 parameters display and Measurement Parameter displays in Tabulation and Graphic way

6. Pneumatic and buffering contact

7. Temperature automatically compensating

8. Voice counts off and prompts, Counting prompt of flash times

9. 24 continuous work

10. Import Xenon Lamp.


Technical Parameter

MODEL

OSCT-A

OSCT-B

Lamp spectrum

In line with iec60904-9

spectral Irradiance distribution requirement(AM1.5)

Light intensity

700-1200W/Mm2 continuous adjustable range

Light intensity non-uniformity

≤±2% A

≤±3%

Light intensity Instability of Irradiance  ( STI )

≤±0.5% A

≤±2% A

Light intensity Non-Uniformity of IrradianceLTI

≤±2%

≤±2%

Test results consistency

≤±0.5%A

≤±1%

Single flash time

10ms

Effective test range

230×230mm/0.1W-12W/5BB-12BB

Measuring voltage

0-0.8V(resolution 1mV)

Measuring current

0-20A(resolution 1mA)

Test parameters

IscVocPmaxVmIm FFEFFTempRsRsh

Power supply

AC220V/50HZ/2KVA

Air supply

0.5-0.8Mpa

Weight

160KGS

140KGS

Machine Dimension

800*600*1750mm

800*600*1850mm


Detail picture

Solar Cell Tester

sun simulator
